Data Structures |
| struct | DEVICE |
| struct | IRP |
| struct | DEVMAN |
| struct | DEVICE_SERVICE_ENTRY_POINTS |
Defines |
| #define | FILE_ATTRIBUTE_ARCHIVE 0x00000020 |
| #define | FILE_ATTRIBUTE_COMPRESSED 0x00000800 |
| #define | FILE_ATTRIBUTE_DIRECTORY 0x00000010 |
| #define | FILE_ATTRIBUTE_ENCRYPTED 0x00004000 |
| #define | FILE_ATTRIBUTE_HIDDEN 0x00000002 |
| #define | FILE_ATTRIBUTE_NORMAL 0x00000080 |
| #define | FILE_ATTRIBUTE_NOT_CONTENT_INDEXED 0x00002000 |
| #define | FILE_ATTRIBUTE_OFFLINE 0x00001000 |
| #define | FILE_ATTRIBUTE_READONLY 0x00000001 |
| #define | FILE_ATTRIBUTE_REPARSE_POINT 0x00000400 |
| #define | FILE_ATTRIBUTE_SPARSE_FILE 0x00000200 |
| #define | FILE_ATTRIBUTE_SYSTEM 0x00000004 |
| #define | FILE_ATTRIBUTE_TEMPORARY 0x00000100 |
| #define | FILE_SUPPORTS_USN_JOURNAL 0x02000000 |
| #define | FILE_SUPPORTS_OPEN_BY_FILE_ID 0x01000000 |
| #define | FILE_SUPPORTS_EXTENDED_ATTRIBUTES 0x00800000 |
| #define | FILE_SUPPORTS_HARD_LINKS 0x00400000 |
| #define | FILE_SUPPORTS_TRANSACTIONS 0x00200000 |
| #define | FILE_SEQUENTIAL_WRITE_ONCE 0x00100000 |
| #define | FILE_READ_ONLY_VOLUME 0x00080000 |
| #define | FILE_NAMED_STREAMS 0x00040000 |
| #define | FILE_SUPPORTS_ENCRYPTION 0x00020000 |
| #define | FILE_SUPPORTS_OBJECT_IDS 0x00010000 |
| #define | FILE_VOLUME_IS_COMPRESSED 0x00008000 |
| #define | FILE_SUPPORTS_REMOTE_STORAGE 0x00000100 |
| #define | FILE_SUPPORTS_REPARSE_POINTS 0x00000080 |
| #define | FILE_SUPPORTS_SPARSE_FILES 0x00000040 |
| #define | FILE_VOLUME_QUOTAS 0x00000020 |
| #define | FILE_FILE_COMPRESSION 0x00000010 |
| #define | FILE_PERSISTENT_ACLS 0x00000008 |
| #define | FILE_UNICODE_ON_DISK 0x00000004 |
| #define | FILE_CASE_PRESERVED_NAMES 0x00000002 |
| #define | FILE_CASE_SENSITIVE_SEARCH 0x00000001 |
Typedefs |
| typedef void(* | pcIRPRequest )(DEVICE *device, IRP *irp) |
| typedef void(* | pcFreeDevice )(DEVICE *device) |
| typedef void(* | pcIRPResponse )(IRP *irp) |
| typedef void(* | pcRegisterDevice )(DEVMAN *devman, DEVICE *device) |
typedef
DEVICE_SERVICE_ENTRY_POINTS * | PDEVICE_SERVICE_ENTRY_POINTS |
| typedef int(* | PDEVICE_SERVICE_ENTRY )(PDEVICE_SERVICE_ENTRY_POINTS) |
Enumerations |
| enum | RDPDR_CTYP { RDPDR_CTYP_CORE = 0x4472,
RDPDR_CTYP_PRN = 0x5052
} |
| enum | RDPDR_PAKID {
PAKID_CORE_SERVER_ANNOUNCE = 0x496E,
PAKID_CORE_CLIENTID_CONFIRM = 0x4343,
PAKID_CORE_CLIENT_NAME = 0x434E,
PAKID_CORE_DEVICELIST_ANNOUNCE = 0x4441,
PAKID_CORE_DEVICE_REPLY = 0x6472,
PAKID_CORE_DEVICE_IOREQUEST = 0x4952,
PAKID_CORE_DEVICE_IOCOMPLETION = 0x4943,
PAKID_CORE_SERVER_CAPABILITY = 0x5350,
PAKID_CORE_CLIENT_CAPABILITY = 0x4350,
PAKID_CORE_DEVICELIST_REMOVE = 0x444D,
PAKID_CORE_USER_LOGGEDON = 0x554C,
PAKID_PRN_CACHE_DATA = 0x5043,
PAKID_PRN_USING_XPS = 0x5543
} |
| enum | RDPDR_CAP_TYPE {
CAP_GENERAL_TYPE = 0x0001,
CAP_PRINTER_TYPE = 0x0002,
CAP_PORT_TYPE = 0x0003,
CAP_DRIVE_TYPE = 0x0004,
CAP_SMARTCARD_TYPE = 0x0005
} |
| enum | RDPDR_CAP_VERSION {
GENERAL_CAPABILITY_VERSION_01 = 0x00000001,
GENERAL_CAPABILITY_VERSION_02 = 0x00000002,
PRINT_CAPABILITY_VERSION_01 = 0x00000001,
PORT_CAPABILITY_VERSION_01 = 0x00000001,
DRIVE_CAPABILITY_VERSION_01 = 0x00000001,
DRIVE_CAPABILITY_VERSION_02 = 0x00000002,
SMARTCARD_CAPABILITY_VERSION_01 = 0x00000001
} |
| enum | IRP_MJ {
IRP_MJ_CREATE = 0x00000000,
IRP_MJ_CLOSE = 0x00000002,
IRP_MJ_READ = 0x00000003,
IRP_MJ_WRITE = 0x00000004,
IRP_MJ_DEVICE_CONTROL = 0x0000000E,
IRP_MJ_QUERY_VOLUME_INFORMATION = 0x0000000A,
IRP_MJ_SET_VOLUME_INFORMATION = 0x0000000B,
IRP_MJ_QUERY_INFORMATION = 0x00000005,
IRP_MJ_SET_INFORMATION = 0x00000006,
IRP_MJ_DIRECTORY_CONTROL = 0x0000000C,
IRP_MJ_LOCK_CONTROL = 0x00000011
} |
| enum | IRP_MN { IRP_MN_QUERY_DIRECTORY = 0x00000001,
IRP_MN_NOTIFY_CHANGE_DIRECTORY = 0x00000002
} |
| enum | FILE_CREATE_DISPOSITION {
FILE_SUPERSEDE = 0x00000000,
FILE_OPEN = 0x00000001,
FILE_CREATE = 0x00000002,
FILE_OPEN_IF = 0x00000003,
FILE_OVERWRITE = 0x00000004,
FILE_OVERWRITE_IF = 0x00000005
} |
| enum | FILE_CREATE_OPTION {
FILE_DIRECTORY_FILE = 0x00000001,
FILE_NON_DIRECTORY_FILE = 0x00000040,
FILE_COMPLETE_IF_OPLOCKED = 0x00000100,
FILE_DELETE_ON_CLOSE = 0x00001000,
FILE_OPEN_REPARSE_POINT = 0x00200000,
FILE_OPEN_FOR_FREE_SPACE_QUERY = 0x00800000
} |
| enum | FILE_RESPONSE { FILE_SUPERSEDED = 0x00000000,
FILE_OPENED = 0x00000001,
FILE_OVERWRITTEN = 0x00000003
} |
| enum | RDPDR_MINOR_RDP_VERSION { RDPDR_MINOR_RDP_VERSION_5_0 = 0x0002,
RDPDR_MINOR_RDP_VERSION_5_1 = 0x0005,
RDPDR_MINOR_RDP_VERSION_5_2 = 0x000A,
RDPDR_MINOR_RDP_VERSION_6_X = 0x000C
} |
| enum | RDPDR_CLIENT_NAME_FLAG { RDPDR_CLIENT_NAME_UNICODE = 0x00000001,
RDPDR_CLIENT_NAME_ASCII = 0x00000000
} |
| enum | RDPDR_CAPS_IRP_MJ {
RDPDR_IRP_MJ_CREATE = 0x00000001,
RDPDR_IRP_MJ_CLEANUP = 0x00000002,
RDPDR_IRP_MJ_CLOSE = 0x00000004,
RDPDR_IRP_MJ_READ = 0x00000008,
RDPDR_IRP_MJ_WRITE = 0x00000010,
RDPDR_IRP_MJ_FLUSH_BUFFERS = 0x00000020,
RDPDR_IRP_MJ_SHUTDOWN = 0x00000040,
RDPDR_IRP_MJ_DEVICE_CONTROL = 0x00000080,
RDPDR_IRP_MJ_QUERY_VOLUME_INFORMATION = 0x00000100,
RDPDR_IRP_MJ_SET_VOLUME_INFORMATION = 0x00000200,
RDPDR_IRP_MJ_QUERY_INFORMATION = 0x00000400,
RDPDR_IRP_MJ_SET_INFORMATION = 0x00000800,
RDPDR_IRP_MJ_DIRECTORY_CONTROL = 0x00001000,
RDPDR_IRP_MJ_LOCK_CONTROL = 0x00002000,
RDPDR_IRP_MJ_QUERY_SECURITY = 0x00004000,
RDPDR_IRP_MJ_SET_SECURITY = 0x00008000
} |
| enum | RDPDR_CAPS_PDU { RDPDR_DEVICE_REMOVE_PDUS = 0x00000001,
RDPDR_CLIENT_DISPLAY_NAME_PDU = 0x00000002,
RDPDR_USER_LOGGEDON_PDU = 0x00000004
} |
| enum | RDPDR_CAPS_FLAG { ENABLE_ASYNCIO = 0x00000001
} |
| enum | RDP_LOWIO_OP { RDP_LOWIO_OP_SHAREDLOCK = 0x00000002,
RDP_LOWIO_OP_EXCLUSIVELOCK = 0x00000003,
RDP_LOWIO_OP_UNLOCK = 0x00000004,
RDP_LOWIO_OP_UNLOCK_MULTIPLE = 0x00000005
} |
| enum | NTSTATUS {
STATUS_SUCCESS = 0x00000000,
STATUS_TIMEOUT = 0x00000102,
STATUS_PENDING = 0x00000103,
STATUS_REPARSE = 0x00000104,
STATUS_MORE_ENTRIES = 0x00000105,
STATUS_NOT_ALL_ASSIGNED = 0x00000106,
STATUS_OPLOCK_BREAK_IN_PROGRESS = 0x00000108,
STATUS_VOLUME_MOUNTED = 0x00000109,
STATUS_NOTIFY_CLEANUP = 0x0000010B,
STATUS_NOTIFY_ENUM_DIR = 0x0000010C,
STATUS_NO_QUOTAS_FOR_ACCOUNT = 0x0000010D,
STATUS_FILE_LOCKED_WITH_ONLY_READERS = 0x0000012A,
STATUS_FILE_LOCKED_WITH_WRITERS = 0x0000012B,
STATUS_WAIT_FOR_OPLOCK = 0x00000367,
STATUS_OBJECT_NAME_EXISTS = 0x40000000,
STATUS_BAD_CURRENT_DIRECTORY = 0x40000007,
STATUS_NO_MORE_FILES = 0x80000006,
STATUS_DEVICE_PAPER_EMPTY = 0x8000000E,
STATUS_DEVICE_POWERED_OFF = 0x8000000F,
STATUS_DEVICE_OFF_LINE = 0x80000010,
STATUS_DEVICE_BUSY = 0x80000011,
STATUS_NO_MORE_ENTRIES = 0x8000001A,
STATUS_UNSUCCESSFUL = 0xC0000001,
STATUS_NOT_IMPLEMENTED = 0xC0000002,
STATUS_INVALID_INFO_CLASS = 0xC0000003,
STATUS_INVALID_HANDLE = 0xC0000008,
STATUS_INVALID_PARAMETER = 0xC000000D,
STATUS_NO_SUCH_DEVICE = 0xC000000E,
STATUS_NO_SUCH_FILE = 0xC000000F,
STATUS_INVALID_DEVICE_REQUEST = 0xC0000010,
STATUS_END_OF_FILE = 0xC0000011,
STATUS_NO_MEDIA_IN_DEVICE = 0xC0000013,
STATUS_UNRECOGNIZED_MEDIA = 0xC0000014,
STATUS_ACCESS_DENIED = 0xc0000022,
STATUS_OBJECT_NAME_INVALID = 0xC0000033,
STATUS_OBJECT_NAME_NOT_FOUND = 0xC0000034,
STATUS_OBJECT_NAME_COLLISION = 0xc0000035,
STATUS_PORT_DISCONNECTED = 0xC0000037,
STATUS_OBJECT_PATH_INVALID = 0xC0000039,
STATUS_OBJECT_PATH_NOT_FOUND = 0xC000003A,
STATUS_INVALID_PORT_HANDLE = 0xC0000042,
STATUS_DELETE_PENDING = 0xC0000056,
STATUS_DISK_FULL = 0xC000007F,
STATUS_DEVICE_NOT_READY = 0xC00000A3,
STATUS_IO_TIMEOUT = 0xC00000B5,
STATUS_FILE_IS_A_DIRECTORY = 0xC00000BA,
STATUS_NOT_SUPPORTED = 0xC00000BB,
STATUS_PRINT_QUEUE_FULL = 0xC00000C6,
STATUS_PRINT_CANCELLED = 0xC00000C8,
STATUS_DIRECTORY_NOT_EMPTY = 0xC0000101,
STATUS_FILE_CORRUPT_ERROR = 0xC0000102,
STATUS_NOT_A_DIRECTORY = 0xC0000103,
STATUS_NAME_TOO_LONG = 0xC0000106,
STATUS_CANCELLED = 0xC0000120,
STATUS_CANNOT_DELETE = 0xC0000121,
STATUS_FILE_DELETED = 0xC0000123,
STATUS_FILE_CLOSED = 0xC0000128
} |
| enum | RDPDR_PRINTER_ANNOUNCE_FLAG {
RDPDR_PRINTER_ANNOUNCE_FLAG_ASCII = 0x00000001,
RDPDR_PRINTER_ANNOUNCE_FLAG_DEFAULTPRINTER = 0x00000002,
RDPDR_PRINTER_ANNOUNCE_FLAG_NETWORKPRINTER = 0x00000004,
RDPDR_PRINTER_ANNOUNCE_FLAG_TSPRINTER = 0x00000008,
RDPDR_PRINTER_ANNOUNCE_FLAG_XPSFORMAT = 0x00000010
} |
| enum | FSCTL_STRUCTURE {
FSCTL_CREATE_OR_GET_OBJECT_ID = 0x900c0,
FSCTL_GET_REPARSE_POINT = 0x900a8,
FSCTL_GET_RETRIEVAL_POINTERS = 0x90073,
FSCTL_IS_PATHNAME_VALID = 0x9002c,
FSCTL_LMR_SET_LINK_TRACKING_INFORMATION = 0x1400ec,
FSCTL_PIPE_PEEK = 0x11400c,
FSCTL_PIPE_TRANSCEIVE = 0x11c017,
FSCTL_PIPE_WAIT = 0x110018,
FSCTL_QUERY_FAT_BPB = 0x90058,
FSCTL_QUERY_ALLOCATED_RANGES = 0x940cf,
FSCTL_QUERY_ON_DISK_VOLUME_INFO = 0x9013c,
FSCTL_QUERY_SPARING_INFO = 0x90138,
FSCTL_READ_FILE_USN_DATA = 0x900eb,
FSCTL_RECALL_FILE = 0x90117,
FSCTL_SET_COMPRESSION = 0x9c040,
FSCTL_SET_DEFECT_MANAGEMENT = 0x98134,
FSCTL_SET_ENCRYPTION = 0x900D7,
FSCTL_SET_OBJECT_ID = 0x90098,
FSCTL_SET_OBJECT_ID_EXTENDED = 0x900bc,
FSCTL_SET_REPARSE_POINT = 0x900a4,
FSCTL_SET_SPARSE = 0x900c4,
FSCTL_SET_ZERO_DATA = 0x980c8,
FSCTL_SET_ZERO_ON_DEALLOCATION = 0x90194,
FSCTL_SIS_COPYFILE = 0x90100,
FSCTL_WRITE_USN_CLOSE_RECORD = 0x900ef
} |
| enum | FILE_FS_DEVICE_TYPE { FILE_DEVICE_CD_ROM = 0x00000002,
FILE_DEVICE_DISK = 0x00000007
} |
| enum | FILE_FS_DEVICE_FLAG {
FILE_REMOVABLE_MEDIA = 0x00000001,
FILE_READ_ONLY_DEVICE = 0x00000002,
FILE_FLOPPY_DISKETTE = 0x00000004,
FILE_WRITE_ONCE_MEDIA = 0x00000008,
FILE_REMOTE_DEVICE = 0x00000010,
FILE_DEVICE_IS_MOUNTED = 0x00000020,
FILE_VIRTUAL_VOLUME = 0x00000040,
FILE_DEVICE_SECURE_OPEN = 0x00000100
} |
| enum | FILE_INFORMATION_CLASS {
FileDirectoryInformation = 1,
FileFullDirectoryInformation,
FileBothDirectoryInformation,
FileBasicInformation,
FileStandardInformation,
FileInternalInformation,
FileEaInformation,
FileAccessInformation,
FileNameInformation,
FileRenameInformation,
FileLinkInformation,
FileNamesInformation,
FileDispositionInformation,
FilePositionInformation,
FileFullEaInformation,
FileModeInformation,
FileAlignmentInformation,
FileAllInformation,
FileAllocationInformation,
FileEndOfFileInformation,
FileAlternateNameInformation,
FileStreamInformation,
FilePipeInformation,
FilePipeLocalInformation,
FilePipeRemoteInformation,
FileMailslotQueryInformation,
FileMailslotSetInformation,
FileCompressionInformation,
FileObjectIdInformation,
FileUnknownInformation1,
FileMoveClusterInformation,
FileQuotaInformation,
FileReparsePointInformation,
FileNetworkOpenInformation,
FileAttributeTagInformation,
FileTrackingInformation,
FileIdBothDirectoryInformation,
FileIdFullDirectoryInformation,
FileValidDataLengthInformation,
FileShortNameInformation
} |
| enum | FILE_FS_INFORMATION_CLASS {
FileFsVolumeInformation = 1,
FileFsLabelInformation,
FileFsSizeInformation,
FileFsDeviceInformation,
FileFsAttributeInformation,
FileFsControlInformation,
FileFsFullSizeInformation,
FileFsObjectIdInformation,
FileFsDriverPathInformation,
FileFsMaximumInformation
} |
